Odyssey Extreme Racing 35 Battery as commonly used in Ginetta G40. G50, G55 and Morgan applications.
MODEL | PHCA** 5 SEC |
CCA* | NOMINAL CAPACITY | RESERVE CAPACITY |
LENGTH (MM) |
WIDTH (MM) |
HEIGHT (MM) |
WEIGHT (KG) |
TERMINALS | |
20 HR RATE | 10 HR RATE | |||||||||
8 | 310 | 100 | 8 Ah | 7 Ah | 9 mins | 138.0 | 86.0 | 101.0 | 2.7 | M4 Bolt |
15 | 370 | 156 | 17 Ah | 14 Ah | 25 mins | 200.0 | 77.0 | 140.0 | 5.7 | M6 Stud |
18 | 535 | 200 | 14 Ah | 13 Ah | 21 mins | 170.2 | 99.1 | 157.0 | 5.4 | M6 Stud |
20 | 545 | 185 | 13 Ah | 12 Ah | 18 mins | 177.8 | 85.6 | 131.3 | 5.7 | M6 BoltT |
22 | 625 | 265 | 18 Ah | 17 Ah | 27 mins | 170.2 | 99.1 | 175.0 | 6.0 | M6 Stud |
25 | 680 | 220 | 16 Ah | 16 Ah | 24 mins | 184.7 | 79.0 | 169.4 | 7.0 | M6 BoltT |
30 | 950 | 450 | 34 Ah | 32 Ah | 60 mins | 250.0 | 97.0 | 156.0 | 9.0 | M6 Stud |
35 | 925 | 380 | 28 Ah | 27 Ah | 52 mins | 168.6 | 179.0 | 128.0 | 11.8 | M6 BoltT |
40 | 1100 | 500 | 50 Ah | 45 Ah | 87 mins | 250.0 | 97.0 | 206.0 | 12.5 | M6 Stud |
* Cold Start Performance S.A.E J537 June 82
** Pulse Current
T Can be fitted with brass automotive terminal
Typical service life at 25°C/77°F: Medium to Heavy Duty 3+ years; Light duty usage 6+ years.
EnerSys® is a global leader in stored energy solutions for automotive, military, and industrial applications. With manufacturing facilities in 17 countries, sales and service locations throughout the world, and over 100 years of battery experience.
EnerSys® are the original manufacturers of the U.K.’s most widely used motorsport batteries, their product having been historically marketed under various popular brand names and now market directly by them under the name of Odyssey.
Built to withstand the extremes of competition, increased vibration resistance allows them to withstand the constant pounding, extreme heat and high vibration that high revving competition engines can generate. They have the performance to start high compression engines using high current draw starters yet remain lightweight and compact.
The ODYSSEY® Extreme Racing™ battery can handle it.
Featuring rugged construction and packed tightly with pure lead plates, the non spillable
AGM design of the ODYSSEY Extreme Racing battery protects against the shock and vibration that can quickly destroy other batteries. The pure lead plates mean more power—twice the overall power and three times the life of conventional batteries.
The ODYSSEY Extreme Racing battery is ideal choice for all motorsport and high performance applications.
